Model |
S5750E-28F-8TP(S5750E-28F-SI-R) |
|
Interface |
16 x 100/1000Base-X (SFP) + 8x GE Combo(GT/SFP) + 4 x 10GE(SFP+) |
|
Management Port |
1x RJ45 Management, 1x console, 1x USB Port |
|
Performance |
|
Switching Capacity |
128Gbps |
|
Throughtput |
95Mbpps |
|
Jumbo Frame |
10K |
|
MAC Address |
16K |
|
CPU |
800MHz |
|
DRAM |
512MB |
|
Flash |
32MB+128MB |
|
ARP Table |
4K |
|
Routing Table |
1K |
|
ACL Table |
1K |
|
Physical |
|
Dimension(W*H*D) |
440mm x 44mm x 240mm |
|
Relative Humidity |
10%~90% non-condensing, storage 95% |
|
Temperature |
Working 0°C~50°C, storage -40°C~70°C |
|
Power supply |
AC:100~240VAC, 50~60Hz + 12V DC RPS |
|
Power consumption |
Max 34W |
|
Main Feature |
|
Standard |
IEEE802.3(10Base-T), IEEE802.3u(100Base-TX), IEEE802.3z(1000BASE-X), IEEE802.3ab(1000Base-T), IEEE802.3ae(10GBase), IEEE802.3x, IEEE802.3ak(10GBASE-CX4) |
|
L2 Feature |
Port loopback detection
LLDP and LLDP-MED
UDLD
802.3ad LACP, max 128 group trunks with max 8 ports for each trunk LACP load balance |
|
N:1 Port Mirroring
RSPAN
ERSPAN |
|
IEEEE802.1d(STP)
L1, L2 Features
IEEEE802.1w(RSTP)
IEEEE802.1s(MSTP)
Root Guard
BPDU Guard
BPDU Tunnel |
|
802.1Q, 4K VLAN
MAC VLAN, Vocie VLAN, PVLAN, Protocol VLAN, Multicast VLAN
QinQ, Flexible QinQ
GVRP
N:1 VLAN Translation
Broadcast / Multicast / Unicast Storm Control |
|
GMP v1/v2/v3 Snooping and L2 Query
ND Snooping
MLDv1/v2 Snooping |
|
Port Security |
|
Flow Control: HOL, IEEE802.3x
Bandwidth Control |
|
L3 Feature |
Static Routing,RIPv1/v2,OSPFv2,BGP4
OSPFv3, BGP4+
OSPF multiple process
LPM Routing
Policy-based Routing(PBR) for IPv4 and IPv6
VRRP
URPF,
ECMP
BFD |
|
IGMP v1/v2/v3, IGMP Proxy,
Static Multicast Route
Multicast Receive Control
Illegal Multicast Source Detect |
|
L3 Feature |
ARP Guard, Local ARP proxy, Proxy ARP, ARP Binding, Gratuitous ARP, ARP Limit
Anti ARP Cheat, Anti ARP Scan |
|
DNS Client, DNS Relay |
|
GRE Tunnel |
|
IPv6 |
6to4 Tunnel, Configured Tunnel, ISATAP Tunnel, GRE Tunnel
ICMPv6,ND,DNSv6
IPv6 LPM Routing,IPv6 Policy-based Routing(PBR)
IPv6 VRRPv3,IPv6 URPF,IPv6 RA
RIPng,OSPFv3,BGP4+
MLD Snooping,IPv6 Multicast VLAN
MLDv1/v2, IPv6 Any Cast RP, IPv6 ACL, IPv6 QoS |
|
QoS
|
8 Queues
SWRR, SP, WRR, WDRR, SWDRR
Traffic Classification Based on 802.1p COS, ToS, DiffServ DSCP, ACL, port number |
|
Traffic Policing
PRI Mark/Remark |
|
ACL |
IP ACL ,MAC ACL,IP-MAC ACL
Standard and Expanded ACL Based on source/destination IP or MAC, IP Protocol, TCP/UDP port, DSCP, ToS, IP
Precedence), VLAN, Tag/Untag, CoS
Redirect and statistics |
|
Security |
802.1x AAA
Port, MAC based authentication
Accounting based on time length and traffic
Guest VLAN and auto VLAN
RADIUS for IPv4 and IPv6
TACACS+ for IPv4 and IPv6
MAB |
|
DHCP |
DHCP Server/Client for IPv4/IPv6
DHCP Relay/Option 82
DHCP Snooping/Option 82 |
|
Traffic Monitor |
sFlow Traffic Analysis |
|
Network Management |
CLI, WEB, Telnet, SNMPv1/v2c/v3 through IPv4 and IPv6
Syslog and external Syslog Server
HTTP SSL
SNMP MIB, SNMP TRAP
FTP/TFTP
SNTP/NTP
RMOM 1,2,3,9
Authentication by Radius/TACACS
SSH v1/v2
Dual firmware images/ Configuration files
802.3ah OAM, 802.1ag OAM |
|
Datacenter feature |
VSF(Virtual Switch Framework) |
|
|
|
|
|
|
